Epson Eb-l520u Wuxga Laser

Tekniset tiedot

3D

No

AC input frequency

50 - 60 Hz

AC input voltage

100 - 240 V

Analog signal format system

Not supported

Aperture range (F-F)

1.5 - 1.7

Audio (L/R) in

1

Batteries included

Yes

Box contents

HDMI Cable, Main unit, Power cable, Remote control incl. batteries, User guide, Warranty Documents

Built-in display

No

Built-in speaker(s)

Yes

Bundled software

EasyMP Multi PC Projection

Cable lock slot

Yes

Cable lock slot type

Kensington

Cables included

AC, HDMI

Card reader integrated

No

Colour modes (2D)

Cinema, Dynamic

Contrast ratio (dynamic)

5000000:1

Contrast ratio (typical)

2500000:1

Control panel

0.67 inch with C2 Fine

Country of origin

Philippines

Depth

304 mm

DVI port

No

Ethernet LAN

Yes

Focal length range

20 - 31.8 mm

Focus

Manual

Full HD

Yes

Harmonized System (HS) code

85286200

HDMI ports quantity

2

Height

122 mm

Interface

RS-232C, VGA in (2x), VGA out, HDMI in (2x), HDBaseT, Miracast (optional), Jack plug out, Jack plug in (2x), USB 2.0-A, USB 2.0, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac (optional)

Keystone correction, horizontal

±30°

Keystone correction, vertical

±30°

Light source type

Laser

Mallinumero

V11HA30040

Market positioning

Presentation

Matrix size

1.7 cm (0.67")

Mobile app support

Yes

Native aspect ratio

16:10

Noise level

31 dB

Noise level (economic mode)

23 dB

Number of built-in speakers

1

Number of colours

1.07 billion colours

Operating relative humidity (H-H)

20 - 80%

Option type

Air filter, Ceiling mount, Document camera, External Speaker, HDBaseT Transmitter, Safety wire set, Suspension adapter, WP System - ELPWP10, Wireless LAN unit, Wireless transmitter - ELPWT01

Other features

21:9 aspect ratio support, A/V mute, Arc Correction, Built-in speaker, CEC compatible, Easy OSD pre-setting, Edge Blending, Long light source life, PC Free, Quick Corner, Screen share, Source function, Ultra-wide display (16:6), iProjection App

Package depth

530 mm

Package height

210 mm

Package weight

10.4 kg

Package width

495 mm

Pallet gross weight

0 g

Pallet weight (UK)

0 g

Placement

Ceiling, Desktop, Floor, Wall

Power consumption

234 Watt (Normal On-Mode), 164 Watt (Eco On-Mode), 293 Watt (Normal Peak-mode), 223 Watt (Eco Peak-Mode), 0.3 Watt (Energy saving standby)

Power consumption (economy mode)

223 W

Power consumption (standby)

0.3 W

Power consumption (typical)

293 W

Power source

AC

Product colour

White

Product type

Standard throw projector

Products per pallet

14 pc(s)

Products per pallet (UK)

14 pc(s)

Projection technology

3LCD

Projector brightness

5200 ANSI lumens

Projector brightness (economic mode)

3640 ANSI lumens

Projector native resolution

WUXGA (1920x1200)

Quantity per pack

1 pc(s)

Remote control included

Yes

RMS rated power

10 W

Screen size compatibility

1270 - 12700 mm (50 - 500")

Security features

Kensington lock, Padlock, Security cable hole, Wireless LAN unit lock

Serial interface type

RS-232C

Service life of light source

20000 h

Service life of light source (economic mode)

30000 h

Software support

via: AMX, Crestron (Network), Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol

Storage relative humidity (H-H)

10 - 90%

Storage temperature (T-T)

-10 - 60 °C

Sustainability certificates

TCO

Throw ratio

1.35 - 2.20:1

USB 2.0 ports quantity

2

USB 2.0 Type-B ports quantity

1

USB display function

3 in 1: Image / Mouse / Sound

Vertical scan range

192 - 240 Hz

VGA (D-Sub) ports quantity

3

Video colour modes

Cinema, DICOM simulation mode, Dynamic, Presentation, sRGB

Video processing

10 bit

Warranty card

Yes

Weight

7.7 kg

Wi-Fi

Yes

Wi-Fi standards

802.11a, Wi-Fi 4 (802.11n)

Width

440 mm

Zoom capability

Yes

Zoom ratio

1.6:1

Zoom type

Manual

EAN / GTIN

8715946695563
