ASUS Pro WS W890-SAGE Emolevy - Intel W890 - Intel LGA4710-2 - DDR5 RAM - SSI (Server)

Tekniset tiedot

12V power connector

Yes

1st M.2 highest PCI Express generation

5.0

1st M.2 largest key size

2280

2nd M.2 highest PCI Express generation

5.0

2nd M.2 largest key size

2280

3rd M.2 highest PCI Express generation

5.0

3rd M.2 largest key size

2280

4th M.2 highest PCI Express generation

5.0

4th M.2 largest key size

2280

ATX Power connector (24-pin)

Yes

Audio chip

Realtek ALC1220P

Audio output channels

7.1 channels

BIOS flashback button

Yes

BIOS memory size

512 Mbit

BIOS type

UEFI AMI

Cables included

SATA, DisplayPort

Chassis intrusion connector

Yes

Clear CMOS button

Yes

Compatible processor series

Intel® Xeon®

Component for

Workstation

Cooling type

Passive

CPU fan connector

Yes

Depth

280 mm

DisplayPort version

1.4

DisplayPorts quantity

2

DVI-D ports quantity

0

ECC сompatibility

ECC

EPS power connector (8-pin)

Yes

Ethernet interface type

2.5 Gigabit Ethernet, 10 Gigabit Ethernet

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

2

Front panel audio connector

Yes

Front panel connector

Yes

HDMI ports quantity

0

Headphone outputs

1

Height

50 mm

Integrated SAS ports

2

Line-in

Yes

Mallinumero

90MB1MW0M0EAY0

Maximum internal memory

4 TB

Maximum resolution

7680 x 4320 pixels

Memory channels

Quad-channel

Memory slots type

DIMM

Motherboard chipset

Intel W890

Motherboard chipset family

Intel

Motherboard form factor

CEB

Number of chassis fan connectors

5

Number of COM connectors

1

Number of CPU fan connectors

2

Number of EPS power connectors (8-pin)

5

Number of HDDs supported

4

Number of M.2 (E) slots

1

Number of M.2 (M) slots

4

Number of memory slots

8

Number of RGB LED pin headers

2

Number of SATA III connectors

4

Number of storage drives supported

10

Number of temperature sensor headers

1

Number of water pump connectors

1

Package depth

320 mm

Package height

100 mm

Package weight

4.12 kg

Package width

376 mm

Parallel processing technology support

Not supported

PCI Express x16 (Gen 4.x) slots

1

PCI Express x16 (Gen 5.x) slots

4

Power source type

ATX

Processor manufacturer

Intel

Processor socket

LGA 4710-2

Product colour

Black

RAID levels

0, 5, 1, 10

RAID support

Yes

RGB LED pin header

Yes

Screws included

Yes

Supported memory types

DDR5-SDRAM

Supported processor sockets

LGA 4710-2

Supported storage drive interfaces

M.2, SATA III, SlimSAS

Supported storage drive types

HDD & SSD

Top Wi-Fi standard

Not available

USB 2.0 connectors

2

USB 2.0 ports quantity

2

USB 3.2 Gen 1 (3.1 Gen 1) connectors

1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

0

USB 3.2 Gen 2 (3.1 Gen 2) connectors

1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

6

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

0

USB4 Gen 3x2 ports quantity

2

VGA (D-Sub) ports quantity

0

Weight

2.75 kg

Wi-Fi

No

Width

305 mm

Windows operating systems supported

Windows 11

EAN / GTIN

4711636390453
