Gigabyte B760 GAMING X DDR4 LGA 1700 ATX -emolevy

Tekniset tiedot

1st M.2 highest PCI Express generation

4.0

1st M.2 largest key size

22110

2nd M.2 highest PCI Express generation

4.0

2nd M.2 largest key size

22110

3rd M.2 highest PCI Express generation

4.0

3rd M.2 largest key size

22110

ACPI version

5.0

ATX Power connector (24-pin)

Yes

Audio chip

Realtek ALC897

Audio output channels

7.1 channels

Batteries included

Yes

Battery capacity

220 mAh

Battery technology

Lithium-Manganese Dioxide (LiMnO2)

Battery type

CR2032

Battery weight

3 g

BIOS memory size

256 Mbit

BIOS type

UEFI AMI

Bundled software

Norton® Internet Security (OEM version)

Clear CMOS jumper

Yes

Compatible processor series

Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i5 12th Gen, Intel Core i5 13th Gen, Intel Core i5 14th Gen, Intel Core i7 12th Gen, Intel Core i7 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen, Intel® Pentium®

Component for

PC

Cooling type

Passive

Country of origin

China

CPU fan connector

Yes

Depth

244 mm

Desktop Management Interface (DMI) version

2.7

DirectX version

12.0

DisplayPort version

1.2

DisplayPorts quantity

1

DVI-D ports quantity

0

ECC сompatibility

ECC & Non-ECC

EPS power connector (8-pin)

Yes

Ethernet interface type

2.5 Gigabit Ethernet

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

1

Front panel audio connector

Yes

Front panel connector

Yes

HDCP

Yes

HDMI ports quantity

1

HDMI version

2.1

Headphone outputs

1

Height

35 mm

Kapasiteetti

128GB

LAN controller

Realtek RTL8125

Line-in

Yes

Lithium weight per battery

0.07 g

Mallinumero

B760GAMINGXD4GEN5

Maximum internal memory

128 GB

Maximum internal memory per slot

32 GB

Maximum internal memory supported by processor

128 GB

Maximum resolution

4096 x 2304 pixels

Memory channels

Dual-channel

Memory slots type

DIMM

Motherboard chipset

Intel B760

Motherboard chipset family

Intel

Motherboard form factor

ATX

Number of battery cells

1

Number of chassis fan connectors

4

Number of CPU fan connectors

2

Number of EPS power connectors (8-pin)

1

Number of HDDs supported

4

Number of M.2 (M) slots

3

Number of memory slots

4

Number of RGB LED pin headers

4

Number of SATA III connectors

4

Number of storage drives supported

7

Number of water pump connectors

2

Package depth

270 mm

Package height

80 mm

Package weight

1.8 kg

Package width

335 mm

Parallel processing technology support

Not supported

PC health monitoring

Fan, Temperature, Voltage, Water cooling

PCI Express x16 (Gen 3.x) slots

2

PCI Express x16 (Gen 5.x) slots

1

Power source type

ATX

Processor manufacturer

Intel

Processor socket

LGA 1700

Product colour

Dark brown

Products per shipping (inner) case

1 pc(s)

RAID levels

0, 1, 5, 10

RAID support

Yes

RGB LED pin header

Yes

S/PDIF out connector

Yes

Screws included

Yes

Serial port headers

1

Supported memory clock speed (max)

5333 MHz

Supported memory clock speeds

2133,2400,2666,2933,3000,3200,3300,3333,3400,3466,3600,3666,3733,3800,3866,4000,4133,4266,4300,4400,4500,4600,4700,4800,4933,5000,5133,5333 MHz

Supported memory types

DDR4-SDRAM

Supported processor sockets

LGA 1700

Supported storage drive interfaces

M.2, PCI Express 4.0, SATA III

Supported storage drive types

HDD & SSD

System Management BIOS (SMBIOS) version

2.7

TPM connector

Yes

Unbuffered memory

Yes

USB 2.0 connectors

2

USB 2.0 ports quantity

5

USB 3.2 Gen 1 (3.1 Gen 1) connectors

1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

0

EAN / GTIN

4719331873448
